KNK Art No.: HDF5HAL
OUTBOARD MOTOR
Max.Output(kw): 3.6
Full Throttle operating range(rpm)4500-5500
Stroke: 4
Cylinder: 1
Displacement(cc): 112
BorexStroke(mm): 59x41
Length x Width x Height(mm): L: 717x361x1156
Weight(kg): L: 24
Weight(lb): L: 53
Gear Ratio: 27: 13(2.08)
Gear Shift Position: F-N-R
Ignition System: TCI
Cooling System: Water-cooling
Starting System: Manual
Control System: Tiller control=Rear control
Capacity of Fuel Tank(L): 12L,external fuel tank available
SHORT SHAFT
Full Throttle operating range(rpm)4500-5500
Stroke: 4
Cylinder: 1
Displacement(cc): 112
BorexStroke(mm): 59x41
Length x Width x Height(mm): L: 717x361x1156
Weight(kg): L: 24
Weight(lb): L: 53
Gear Ratio: 27: 13(2.08)
Gear Shift Position: F-N-R
Ignition System: TCI
Cooling System: Water-cooling
Starting System: Manual
Control System: Tiller control=Rear control
Capacity of Fuel Tank(L): 12L,external fuel tank available
SHORT SHAFT
OEM NO & Reference No.
CE MODEL:F5
Fit For Models.
SEANOVO HDF5HAL
Related Manuals/Videos/Tables
Related Brands (Replacement Parts)
Related Categories
↘︎SPARE PARTS LIST
INDEX
| No. | KNK Art No. | Description | Qty | Button |
|---|
| 1 | F4-07.00.00 |
顶罩组件 Top cowling assy | 1 | More Info |
| 2 | F4-01.01.00 |
启动罩组件 Starter cover assy. | 1 | More Info |
| 3 | F4-01.06.00 |
动力系统 Power system | 1 | More Info |
| 4 | F4-01.07.00 |
燃油系统 Fuel system | 1 | More Info |
| 5 | F4-02.00.00 |
底罩部件 Bottom cowling parts | 1 | More Info |
| 6 | F4-03.00.00 |
夹紧托架部件 Clamp Bracket | 1 | More Info |
| 7 | F4-06.00.00 |
水下驱动部件 lower driving comp. | 1 | More Info |
| 8 | F4-05.00.00 |
水上部件 upper casing comp. | 1 | More Info |
| 9 | F4-04.00.00 |
操舵部件 steering comp. | 1 | More Info |
