KNK Art No.: KM1E36F-2
2 Stroke GASOLINE Engine
Displacement: 32.6cc/36×32mm
Max power: 0.9kw/1.2HP
Fuel tank: 0.75L
N.W.: 3.4kgs
Packing: 29×25×24cm
20"FCL: 1700PCS
Max power: 0.9kw/1.2HP
Fuel tank: 0.75L
N.W.: 3.4kgs
Packing: 29×25×24cm
20"FCL: 1700PCS
Product Net Weight
3400g ≈ 3.4 kgs ≈ 119.93oz ≈ 7.5lbs
Fit For Model (Replacement Parts)
Related Brands (Replacement Parts)
Related Categories
↘︎SPARE PARTS LIST
| No. | KNK Art No. | Description | Qty | Button |
|---|
| E1 | KM0408330-E1 | SCREW | 1 | More Info |
| E2 | KM0408330-E2 | RATCHET | 1 | More Info |
| E3 | KM0408330-E3 | STARTER ROPE REEL | 1 | More Info |
| E4 | KM0408330-E4 | STARTER ROPE | 1 | More Info |
| E5 | KM0408330-E5 | RECOIL SPRING | 1 | More Info |
| E6 | KM0408330-E6 | STARTER BODY | 1 | More Info |
| E7 | KM0408330-E7 | SCREW M5*20 | 5 | More Info |
| E8 | KM0408330-E8 | STARTER HANDLE | 1 | More Info |
| E9 | KM0408330-E9 | RING | 1 | More Info |
| E10 | KM0408330-E10 | SPRING | 1 | More Info |
| E11 | KM0408330-E11 | STARTER POLE | 2 | More Info |
| E12 | KM0408330-E12 | STARTER | 1 | More Info |
| E13 | KM0408330-E13 | STARTER GASKET | 1 | More Info |
| E14 | KM0408330-E14 | STARTER REEL | 1 | More Info |
| E15 | KM0408330-E15 | OIL SEAL | 1 | More Info |
| E16 | KM0408330-E16 | CRANK CASE | 1 | More Info |
| E17 | KM0408330-E17 | CRANK CASE GASKET | 1 | More Info |
| E18 | KM0408330-E18 | BEARING 6201/P5 | 2 | More Info |
| E19 | KM0408330-E19 | CRANK SHAFT | 1 | More Info |
| E20 | KM0408330-E20 | KEY 3*5*13 | 1 | More Info |
| E21 | KM0408330-E21 | PIN B4*10 | 2 | More Info |
| E22 | KM0408330-E22 | CRANK CASE | 1 | More Info |
| E23 | KM0408330-E23 | SCERW M5*30 | 4 | More Info |
| E24 | KM0408330-E24 | FLYWHEEL | 1 | More Info |
| E25 | KM0408330-E25 | FLAT WASHER | 1 | More Info |
| E26 | KM0408330-E26 | WAVE WASHER | 1 | More Info |
| E27 | KM0408330-E27 | NUT M8 | 1 | More Info |
| E28 | KM0408330-E28 | IGNITION | 1 | More Info |
| E29 | KM0408330-E29 | WIRE | 1 | More Info |
| E30 | KM0408330-E30 | BOLT M5*20 | 6 | More Info |
| E31 | KM0408330-E31 | FLAT WASHER | 2 | More Info |
| E32 | KM0408330-E32 | SPRING | 1 | More Info |
| E33 | KM0408330-E33 | EXPANDER | 2 | More Info |
| E34 | KM0408330-E34 | WAVE WASHER | 2 | More Info |
| E35 | KM0408330-E35 | SCREW PIN | 2 | More Info |
| E37 | KM0408330-E37 | FAN COVER | 1 | More Info |
| E39 | KM0408330-E39 | NEEDLE BEARING | 1 | More Info |
| E40 | KM0408330-E40 | RING | 2 | More Info |
| E41 | KM0408330-E41 | PISTON PIN | 1 | More Info |
| E42 | KM0408330-E42 | PISTON | 2 | More Info |
| E43 | KM0408330-E43 | PISTON RING | 2 | More Info |
| E44 | KM0408330-E44 | CYLINDER GASKET | 1 | More Info |
| E45 | KM0408330-E45 | CYLINDER | 1 | More Info |
| E46 | KM0408330-E46 | SCREW M5*18 | 4 | More Info |
| E47 | KM0408330-E47 | GUIDE COVER | 1 | More Info |
| E48 | KM0408330-E48 | SPARK PLUG | 1 | More Info |
| E49 | KM0408330-E49 | SPRING | 1 | More Info |
| E50 | KM0408330-E50 | PLUG CAP | 1 | More Info |
| E51 | KM0408330-E51 | CAP | 1 | More Info |
| E52 | KM0408330-E52 | PLUG | 1 | More Info |
| E53 | KM0408330-E53 | COVER | 1 | More Info |
| E54 | KM0408330-E54 | MUFFLER GASKET | 1 | More Info |
| E55 | KM0408330-E55 | MUFFLER | 1 | More Info |
| E56 | KM0408330-E56 | SCREW M5*12 | 3 | More Info |
| E57 | KM0408330-E57 | BOLT | 2 | More Info |
| E59 | KM0408330-E59 | MUFFLER COVER | 1 | More Info |
| E60 | KM0408330-E60 | ADMMITING PIPE GASKET | 1 | More Info |
| E61 | KM0408330-E61 | ADMITTING PIPE | 1 | More Info |
| E62 | KM0408330-E62 | CARBURETOR GASKET | 1 | More Info |
| E63 | KM0408330-E63 | CARBURETOR | 1 | More Info |
| E64 | KM0408330-E64 | CHOKER HANDLE | 1 | More Info |
| E67 | KM0408330-E67 | CLEANER INSIDE COVER | 1 | More Info |
| E68 | KM0408330-E68 | SCREW M5*50 | 2 | More Info |
| E69 | KM0408330-E69 | CHOKER | 1 | More Info |
| E70 | KM0408330-E70 | SCREW ST4.2*12 | 1 | More Info |
| E71 | KM0408330-E71 | AIR FILTER | 1 | More Info |
| E72 | KM0408330-E72 | CLEANER OUTSIDE COVER | 1 | More Info |
| E73 | KM0408330-E73 | KNOB | 1 | More Info |
| E75 | KM0408330-E75 | RUBBER COVER | 1 | More Info |
| E76 | KM0408330-E76 | FUEL FILTER | 1 | More Info |
| E77 | KM0408330-E77 | FUEL PIPE (LONG) | 1 | More Info |
| E78 | KM0408330-E78 | PLUG | 1 | More Info |
| E79 | KM0408330-E79 | FUEL PIPE (SHORT) | 1 | More Info |
| E80 | KM0408330-E80 | SCREW M5*16 | 2 | More Info |
| E81 | KM0408330-E81 | FUEL TANK | 1 | More Info |
| E82 | KM0408330-E82 | CHAIN | 1 | More Info |
| E83 | KM0408330-E83 | END COVER | 1 | More Info |
| E84 | KM0408330-E84 | INSIDE COVER | 1 | More Info |
| E85 | KM0408330-E85 | INLET | 1 | More Info |
| E86 | KM0408330-E86 | O RING | 1 | More Info |
| E87 | KM0408330-E87 | FUEL TANK LID | 1 | More Info |
| E88 | KM0408330-E88 | FUEL TANK LID ASSY. | 1 | More Info |
| E89 | KM0408330-E89 | RUBBER CUSHION | 2 | More Info |
| E92 | KM0408330-E92 | STAND | 1 | More Info |
