KNK Art No.: KM0403520
49.3CC CHAIN SAW
Engine/Bore: 49.3cc/43.5mm*31mm
Power: 2.2kw/2.8HP
Fuel consumption: 560g/kwh
Rim Sprocket: 7 teeth x 0.325"
Bar & chain: 0.325"x 0.058"(72links=18")
N.W./G.W: 6.8/8.5kgs
20'FCL: 462PCS
WALBRO CARB/OREGON CHAIN/CHINA BAR
Power: 2.2kw/2.8HP
Fuel consumption: 560g/kwh
Rim Sprocket: 7 teeth x 0.325"
Bar & chain: 0.325"x 0.058"(72links=18")
N.W./G.W: 6.8/8.5kgs
20'FCL: 462PCS
WALBRO CARB/OREGON CHAIN/CHINA BAR
OEM NO & Reference No.
BFK4930
Product New Weight
6800g ≈ 6.8 kgs ≈ 239.86oz ≈ 14.99lbs
Fit For Model (Replacement Parts)
Related Brands (Replacement Parts)
Related Categories
↘︎SPARE PARTS LIST
| No. | KNK Art No. | Description | Qty | Button |
|---|
| 01 | KM0403520-01 | CYLINDER | 1 | More Info |
| 10 | KM0403520-10 | KEY | 1 | More Info |
| 100 | KM0403520-100 | BRAKE COMP. | 1 | More Info |
| 101 | KM0403520-101 | BRAKE LEVER | 1 | More Info |
| 102 | KM0403520-102 | SCREW ST3.8*8 | 3 | More Info |
| 103 | KM0403520-103 | SPRING COVER | 1 | More Info |
| 104 | KM0403520-104 | PIN | 1 | More Info |
| 105 | KM0403520-105 | BRAKE BAND | 1 | More Info |
| 106 | KM0403520-106 | THICK SPRING | 1 | More Info |
| 107 | KM0403520-107 | THIN SPRING | 1 | More Info |
| 108 | KM0403520-108 | RUBBER CUSHION E | 1 | More Info |
| 109 | KM0403520-109 | SPRING PUSHER | 1 | More Info |
| 11 | KM0403520-11 | MUFFLER NUT M5 | 2 | More Info |
| 110 | KM0403520-110 | PIN | 1 | More Info |
| 111 | KM0403520-111 | CONNECTOR | 1 | More Info |
| 112 | KM0403520-112 | CIRCLIP | 1 | More Info |
| 113 | KM0403520-113 | HOLLOW PIN | 1 | More Info |
| 114 | KM0403520-114 | PIN | 1 | More Info |
| 115 | KM0403520-115 | CONNECTION PLATE | 1 | More Info |
| 116 | KM0403520-116 | RUBBER RING | 1 | More Info |
| 117 | KM0403520-117 | WASHER | 1 | More Info |
| 118 | KM0403520-118 | TORSIONAL SPRING | 1 | More Info |
| 119 | KM0403520-119 | PLASTIC PAD | 1 | More Info |
| 12 | KM0403520-12 | MUFFLER PLATE | 1 | More Info |
| 120 | KM0403520-120 | SCREW | 1 | More Info |
| 121 | KM0403520-121 | PRESSING PLATE | 1 | More Info |
| 122 | KM0403520-122 | BAR ADJUSTOR A | 1 | More Info |
| 123 | KM0403520-123 | BAR ADJUSTOR B | 1 | More Info |
| 124 | KM0403520-124 | BAR ADUSTOR C | 1 | More Info |
| 125 | KM0403520-125 | BAR ADJUSTOR SCREW COMP. | 1 | More Info |
| 126 | KM0403520-126 | CIRCLIP | 1 | More Info |
| 127 | KM0403520-127 | PIN | 1 | More Info |
| 128 | KM0403520-128 | RUBBER BAND | 1 | More Info |
| 129 | KM0403520-129 | BRAKE BODY | 1 | More Info |
| 13 | KM0403520-13 | SCREW | 5 | More Info |
| 130 | KM0403520-130 | TRIGGER COVER | 1 | More Info |
| 131 | KM0403520-131 | TRIGGER CONTROL LEVER | 1 | More Info |
| 132 | KM0403520-132 | RUBBER CUSHION (LONG) | 2 | More Info |
| 133 | KM0403520-133 | PIN | 1 | More Info |
| 134 | KM0403520-134 | SPRING | 1 | More Info |
| 135 | KM0403520-135 | TRIGGER | 1 | More Info |
| 136 | KM0403520-136 | FUEL TANK | 1 | More Info |
| 137 | KM0403520-137 | SCREW ST4.8*18 | 1 | More Info |
| 138 | KM0403520-138 | PRIMER BULB | 1 | More Info |
| 139 | KM0403520-139 | BENT PIPE | 1 | More Info |
| 14 | KM0403520-14 | MUFFLER | 1 | More Info |
| 140 | KM0403520-140 | FUEL FILTER | 1 | More Info |
| 141 | KM0403520-141 | FUEL PIPE | 1 | More Info |
| 142 | KM0403520-142 | AIR CHECK VALVE BASE | 1 | More Info |
| 143 | KM0403520-143 | AIR CHECK VALVE BASE | 1 | More Info |
| 144 | KM0403520-144 | PIPE | 1 | More Info |
| 145 | KM0403520-145 | PIPE PROTECTION SPRING | 1 | More Info |
| 146 | KM0403520-146 | SNAP RING | 1 | More Info |
| 147 | KM0403520-147 | PIPE | 1 | More Info |
| 148 | KM0403520-148 | SWITCH | 1 | More Info |
| 149 | KM0403520-149 | WIRE | 1 | More Info |
| 15 | KM0403520-15 | BOLT M5*83 | 2 | More Info |
| 150 | KM0403520-150 | RUBBER CUSHION F | 1 | More Info |
| 151 | KM0403520-151 | O RING | 1 | More Info |
| 152 | KM0403520-152 | FUEL TANK CAP | 1 | More Info |
| 153 | KM0403520-153 | BALE HANDLE | 1 | More Info |
| 154 | KM0403520-154 | STARTER HANDLE | 1 | More Info |
| 155 | KM0403520-155 | STARTER ROPE | 1 | More Info |
| 156 | KM0403520-156 | STARTER BODY | 1 | More Info |
| 156A | KM0403520-156A | E-STARTER BODY | 1 | More Info |
| 157 | KM0403520-157 | COIL SPRING | 1 | More Info |
| 158 | KM0403520-158 | COIL SPRING BASE | 1 | More Info |
| 159 | KM0403520-159 | COIL SPRING PLUS BASE | 1 | More Info |
| 159A | KM0403520-159A | COIL SPRING PLUS BASE (FOR E-STARTER) | 1 | More Info |
| 159B | KM0403520-159B | COIL SPRING (FOR E-STARTER) | 1 | More Info |
| 16 | KM0403520-16 | MUFFLER GASKET | 1 | More Info |
| 160 | KM0403520-160 | ROPE REEL | 1 | More Info |
| 160A | KM0403520-160A | ROPE REEL (FOR E-STARTER) | 1 | More Info |
| 161 | KM0403520-161 | WASHER | 1 | More Info |
| 162 | KM0403520-162 | SCREW | 1 | More Info |
| 163 | KM0403520-163 | SAW CHAIN | 1 | More Info |
| 164 | KM0403520-164 | GUIDE BAR | 1 | More Info |
| 165 | KM0403520-165 | GUIDE BAR COVER | 1 | More Info |
| 166 | KM0403520-166 | GUIDE BAR | 1 | More Info |
| 167 | KM0403520-167 | GUIDE BAR COVER | 1 | More Info |
| 168 | KM0403520-168 | CYLINDER PISTON KIT | 1 | More Info |
| 17 | KM0403520-17 | SCREW M5*20 | 6 | More Info |
| 18 | KM0403520-18 | SPARK PLUG | 1 | More Info |
| 19 | KM0403520-19 | INTAKE PIPE GASKET | 1 | More Info |
| 02 | KM0403520-02 | CYLINDER GASKET | 1 | More Info |
| 20 | KM0403520-20 | SCREW M5*12 | 2 | More Info |
| 21 | KM0403520-21 | INTAKE PIPE | 1 | More Info |
| 22 | KM0403520-22 | INTAKE PIPE SUPPORTOR | 1 | More Info |
| 23 | KM0403520-23 | INTAKE PIPE SUPPORTOR GASKET | 1 | More Info |
| 24 | KM0403520-24 | FLANGE | 1 | More Info |
| 25 | KM0403520-25 | COPPER RING | 1 | More Info |
| 26 | KM0403520-26 | CARBURETOR | 1 | More Info |
| 27 | KM0403520-27 | GROMMAT INNER | 1 | More Info |
| 28 | KM0403520-28 | BOLT M5*50 | 2 | More Info |
| 29 | KM0403520-29 | RUBBER PAD | 1 | More Info |
| 03 | KM0403520-03 | PISTON RING | 2 | More Info |
| 30 | KM0403520-30 | AIR FILTER O RING | 1 | More Info |
| 31 | KM0403520-31 | AIR FILTER | 1 | More Info |
| 32 | KM0403520-32 | KNOB | 1 | More Info |
| 33 | KM0403520-33 | WASHER | 1 | More Info |
| 34 | KM0403520-34 | AIR FILTER COVER | 1 | More Info |
| 35 | KM0403520-35 | SCREW M5*14 | 14 | More Info |
| 36 | KM0403520-36 | CYLINDER COVER | 1 | More Info |
| 37 | KM0403520-37 | STARTER COMP. (NORMAL TYPE) | 1 | More Info |
| 37A | KM0403520-37A | STARTER COMP. (E-STARTER TYPE) | 1 | More Info |
| 38 | KM0403520-38 | FAN COVER | 1 | More Info |
| 39 | KM0403520-39 | NUT M8 | 3 | More Info |
| 04 | KM0403520-04 | SNAP RING | 2 | More Info |
| 40 | KM0403520-40 | FLYWHEEL COMP. | 1 | More Info |
| 41 | KM0403520-41 | SCREW | 2 | More Info |
| 42 | KM0403520-42 | CLAW | 2 | More Info |
| 43 | KM0403520-43 | TORSIONAL SPRING | 2 | More Info |
| 44 | KM0403520-44 | DUST-PROOF CAP | 1 | More Info |
| 45 | KM0403520-45 | IGNITION CAP | 1 | More Info |
| 46 | KM0403520-46 | IGNITION SPRING | 1 | More Info |
| 47 | KM0403520-47 | IGNITION COIL | 1 | More Info |
| 48 | KM0403520-48 | IGNITION COIL COMP. | 1 | More Info |
| 49 | KM0403520-49 | SCREW M4*6 | 2 | More Info |
| 05 | KM0403520-05 | PISTON PIN | 1 | More Info |
| 50 | KM0403520-50 | PRESSING PLATE | 1 | More Info |
| 51 | KM0403520-51 | SCREW M5*30 | 5 | More Info |
| 52 | KM0403520-52 | OIL SEAL 15 35 5 | 1 | More Info |
| 53 | KM0403520-53 | CIRCLIP | 1 | More Info |
| 54 | KM0403520-54 | BEARING 6202 | 2 | More Info |
| 55 | KM0403520-55 | OIL TANK CAP | 1 | More Info |
| 56 | KM0403520-56 | OIL TANK CAP O RING | 1 | More Info |
| 57 | KM0403520-57 | RUBBER CUSHION PLUG | 5 | More Info |
| 58 | KM0403520-58 | SCREW ST4.8*13 | 8 | More Info |
| 59 | KM0403520-59 | RUBBER CUSHION (SHORT) | 3 | More Info |
| 06 | KM0403520-06 | PISTON | 1 | More Info |
| 60 | KM0403520-60 | CRANK CASE (LEFT) | 1 | More Info |
| 61 | KM0403520-61 | RUBBER CUSHION A | 1 | More Info |
| 62 | KM0403520-62 | RUBBER CUSHION B | 1 | More Info |
| 63 | KM0403520-63 | CARBURETOR DUST-PROOF PLUG | 1 | More Info |
| 64 | KM0403520-64 | CRANK CASE GASKET | 1 | More Info |
| 65 | KM0403520-65 | STEEL WIRE | 1 | More Info |
| 66 | KM0403520-66 | CRANK CASE DUST-PROOF PLUG | 1 | More Info |
| 67 | KM0403520-67 | CRANK CASE (RIGHT) | 1 | More Info |
| 68 | KM0403520-68 | PIN 5*10 | 3 | More Info |
| 69 | KM0403520-69 | DENTIFORM PLATE | 1 | More Info |
| 07 | KM0403520-07 | NEEDLE BEARING SNAP RING | 2 | More Info |
| 70 | KM0403520-70 | CARBURETOR SUPPORTOR GASKET | 1 | More Info |
| 71 | KM0403520-71 | STUD | 2 | More Info |
| 72 | KM0403520-72 | OIL FILTER | 1 | More Info |
| 73 | KM0403520-73 | OIL PIPE | 1 | More Info |
| 74 | KM0403520-74 | OIL SEAL 15 28 5 | 1 | More Info |
| 75 | KM0403520-75 | RUBBER CUSHION C | 1 | More Info |
| 76 | KM0403520-76 | AIR CHECK VALVE | 1 | More Info |
| 77 | KM0403520-77 | SPONGE | 1 | More Info |
| 78 | KM0403520-78 | SNAP RING | 1 | More Info |
| 79 | KM0403520-79 | RUBBER CUSHION D | 1 | More Info |
| 08 | KM0403520-08 | NEEDLE BEARING | 1 | More Info |
| 80 | KM0403520-80 | CHOKE ROD RING | 1 | More Info |
| 81 | KM0403520-81 | CHOKE ROD | 1 | More Info |
| 82 | KM0403520-82 | TURRIFORM SPRING | 1 | More Info |
| 83 | KM0403520-83 | TURRIFORM SPRING BASE | 1 | More Info |
| 84 | KM0403520-84 | CHAIN CATCHER | 1 | More Info |
| 85 | KM0403520-85 | OIL PUMP | 1 | More Info |
| 86 | KM0403520-86 | OIL OUTLET PIPE | 1 | More Info |
| 87 | KM0403520-87 | SCREW M4*12 | 5 | More Info |
| 88 | KM0403520-88 | WORM | 1 | More Info |
| 89 | KM0403520-89 | OIL PUMP COVER | 1 | More Info |
| 09 | KM0403520-09 | CRANK SHAFT | 1 | More Info |
| 90 | KM0403520-90 | CLUTCH NEEDLE BEARING | 1 | More Info |
| 91 | KM0403520-91 | RIM SPROCKET | 1 | More Info |
| 92 | KM0403520-92 | CLUTCH DRUM | 1 | More Info |
| 93 | KM0403520-93 | WASHER | 1 | More Info |
| 94 | KM0403520-94 | PRESSING PLATE | 1 | More Info |
| 95 | KM0403520-95 | SCREW M4*10 | 1 | More Info |
| 96 | KM0403520-96 | CLUTCH EXPANDER SHOE | 3 | More Info |
| 97 | KM0403520-97 | CLUTCH EXPANDER HOLDER | 1 | More Info |
| 98 | KM0403520-98 | CLUTCH EXPANDER SPRING | 1 | More Info |
| 99 | KM0403520-99 | CLUTCH EXPANDER COMP. | 1 | More Info |
