KNK Art No.: KM0403450
45CC GASOLINE CHAIN SAW
Engine/Bore: 45cc/43mm*31mm
Power: 1.8kw/2.5HP
Fuel consumption: 560g/kwh
Rim Sprocket: 7 teeth
Bar & chain: 3/8"x 0.050"(72links=18")
N.W./G.W: 6.7/8.4kgs
20'FCL: 462PCS
CHINA CARB/CHAIN/BAR
Power: 1.8kw/2.5HP
Fuel consumption: 560g/kwh
Rim Sprocket: 7 teeth
Bar & chain: 3/8"x 0.050"(72links=18")
N.W./G.W: 6.7/8.4kgs
20'FCL: 462PCS
CHINA CARB/CHAIN/BAR
Product Net Weight
6700g ≈ 6.7 kgs ≈ 236.33oz ≈ 14.77lbs
Fit For Model (Replacement Parts)
Related Brands (Replacement Parts)
Related Categories
↘︎SPARE PARTS LIST
| No. | KNK Art No. | Description | Qty | Button |
|---|
| 01 | KM0403450-01 | CYLINDER | 1 | More Info |
| 10 | KM0403450-10 | KEY | 1 | More Info |
| 100 | KM0403450-100 | BRAKE COMP. | 1 | More Info |
| 101 | KM0403450-101 | BRAKE LEVER | 1 | More Info |
| 102 | KM0403450-102 | SCREW ST3.8*8 | 3 | More Info |
| 103 | KM0403450-103 | SPRING COVER | 1 | More Info |
| 104 | KM0403450-104 | PIN | 1 | More Info |
| 105 | KM0403450-105 | BRAKE BAND | 1 | More Info |
| 106 | KM0403450-106 | THICK SPRING | 1 | More Info |
| 107 | KM0403450-107 | THIN SPRING | 1 | More Info |
| 108 | KM0403450-108 | RUBBER CUSHION E | 1 | More Info |
| 109 | KM0403450-109 | SPRING PUSHER | 1 | More Info |
| 11 | KM0403450-11 | MUFFLER NUT M5 | 2 | More Info |
| 110 | KM0403450-110 | PIN | 1 | More Info |
| 111 | KM0403450-111 | CONNECTOR | 1 | More Info |
| 112 | KM0403450-112 | CIRCLIP | 1 | More Info |
| 113 | KM0403450-113 | HOLLOW PIN | 1 | More Info |
| 114 | KM0403450-114 | PIN | 1 | More Info |
| 115 | KM0403450-115 | CONNECTION PLATE | 1 | More Info |
| 116 | KM0403450-116 | RUBBER RING | 1 | More Info |
| 117 | KM0403450-117 | WASHER | 1 | More Info |
| 118 | KM0403450-118 | TORSIONAL SPRING | 1 | More Info |
| 119 | KM0403450-119 | PLASTIC PAD | 1 | More Info |
| 12 | KM0403450-12 | MUFFLER PLATE | 1 | More Info |
| 120 | KM0403450-120 | SCREW | 1 | More Info |
| 121 | KM0403450-121 | PRESSING PLATE | 1 | More Info |
| 122 | KM0403450-122 | BAR ADJUSTOR A | 1 | More Info |
| 123 | KM0403450-123 | BAR ADJUSTOR B | 1 | More Info |
| 124 | KM0403450-124 | BAR ADUSTOR C | 1 | More Info |
| 125 | KM0403450-125 | BAR ADJUSTOR SCREW COMP. | 1 | More Info |
| 126 | KM0403450-126 | CIRCLIP | 1 | More Info |
| 127 | KM0403450-127 | PIN | 1 | More Info |
| 128 | KM0403450-128 | RUBBER BAND | 1 | More Info |
| 129 | KM0403450-129 | BRAKE BODY | 1 | More Info |
| 13 | KM0403450-13 | SCREW | 5 | More Info |
| 130 | KM0403450-130 | TRIGGER COVER | 1 | More Info |
| 131 | KM0403450-131 | TRIGGER CONTROL LEVER | 1 | More Info |
| 132 | KM0403450-132 | RUBBER CUSHION (LONG) | 2 | More Info |
| 133 | KM0403450-133 | PIN | 1 | More Info |
| 134 | KM0403450-134 | SPRING | 1 | More Info |
| 135 | KM0403450-135 | TRIGGER | 1 | More Info |
| 136 | KM0403450-136 | FUEL TANK | 1 | More Info |
| 137 | KM0403450-137 | SCREW ST4.8*18 | 1 | More Info |
| 138 | KM0403450-138 | PRIMER BULB | 1 | More Info |
| 139 | KM0403450-139 | BENT PIPE | 1 | More Info |
| 14 | KM0403450-14 | MUFFLER | 1 | More Info |
| 140 | KM0403450-140 | FUEL FILTER | 1 | More Info |
| 141 | KM0403450-141 | FUEL PIPE | 1 | More Info |
| 142 | KM0403450-142 | AIR CHECK VALVE BASE | 1 | More Info |
| 143 | KM0403450-143 | AIR CHECK VALVE BASE | 1 | More Info |
| 144 | KM0403450-144 | PIPE | 1 | More Info |
| 145 | KM0403450-145 | PIPE PROTECTION SPRING | 1 | More Info |
| 146 | KM0403450-146 | SNAP RING | 1 | More Info |
| 147 | KM0403450-147 | PIPE | 1 | More Info |
| 148 | KM0403450-148 | SWITCH | 1 | More Info |
| 149 | KM0403450-149 | WIRE | 1 | More Info |
| 15 | KM0403450-15 | BOLT M5*83 | 2 | More Info |
| 150 | KM0403450-150 | RUBBER CUSHION F | 1 | More Info |
| 151 | KM0403450-151 | O RING | 1 | More Info |
| 152 | KM0403450-152 | FUEL TANK CAP | 1 | More Info |
| 153 | KM0403450-153 | BALE HANDLE | 1 | More Info |
| 154 | KM0403450-154 | STARTER HANDLE | 1 | More Info |
| 155 | KM0403450-155 | STARTER ROPE | 1 | More Info |
| 156 | KM0403450-156 | STARTER BODY | 1 | More Info |
| 156A | KM0403450-156A | E-STARTER BODY | 1 | More Info |
| 157 | KM0403450-157 | COIL SPRING | 1 | More Info |
| 158 | KM0403450-158 | COIL SPRING BASE | 1 | More Info |
| 159 | KM0403450-159 | COIL SPRING PLUS BASE | 1 | More Info |
| 159A | KM0403450-159A | COIL SPRING PLUS BASE (FOR E-STARTER) | 1 | More Info |
| 159B | KM0403450-159B | COIL SPRING (FOR E-STARTER) | 1 | More Info |
| 16 | KM0403450-16 | MUFFLER GASKET | 1 | More Info |
| 160 | KM0403450-160 | ROPE REEL | 1 | More Info |
| 160A | KM0403450-160A | ROPE REEL (FOR E-STARTER) | 1 | More Info |
| 161 | KM0403450-161 | WASHER | 1 | More Info |
| 162 | KM0403450-162 | SCREW | 1 | More Info |
| 163 | KM0403450-163 | SAW CHAIN | 1 | More Info |
| 164 | KM0403450-164 | GUIDE BAR | 1 | More Info |
| 165 | KM0403450-165 | GUIDE BAR COVER | 1 | More Info |
| 166 | KM0403450-166 | GUIDE BAR | 1 | More Info |
| 167 | KM0403450-167 | GUIDE BAR COVER | 1 | More Info |
| 168 | KM0403450-168 | CYLINDER PISTON KIT | 1 | More Info |
| 17 | KM0403450-17 | SCREW M5*20 | 6 | More Info |
| 18 | KM0403450-18 | SPARK PLUG | 1 | More Info |
| 19 | KM0403450-19 | INTAKE PIPE GASKET | 1 | More Info |
| 02 | KM0403450-02 | CYLINDER GASKET | 1 | More Info |
| 20 | KM0403450-20 | SCREW M5*12 | 2 | More Info |
| 21 | KM0403450-21 | INTAKE PIPE | 1 | More Info |
| 22 | KM0403450-22 | INTAKE PIPE SUPPORTOR | 1 | More Info |
| 23 | KM0403450-23 | INTAKE PIPE SUPPORTOR GASKET | 1 | More Info |
| 24 | KM0403450-24 | FLANGE | 1 | More Info |
| 25 | KM0403450-25 | COPPER RING | 1 | More Info |
| 26 | KM0403450-26 | CARBURETOR | 1 | More Info |
| 27 | KM0403450-27 | GROMMAT INNER | 1 | More Info |
| 28 | KM0403450-28 | BOLT M5*50 | 2 | More Info |
| 29 | KM0403450-29 | RUBBER PAD | 1 | More Info |
| 03 | KM0403450-03 | PISTON RING | 2 | More Info |
| 30 | KM0403450-30 | AIR FILTER O RING | 1 | More Info |
| 31 | KM0403450-31 | AIR FILTER | 1 | More Info |
| 32 | KM0403450-32 | KNOB | 1 | More Info |
| 33 | KM0403450-33 | WASHER | 1 | More Info |
| 34 | KM0403450-34 | AIR FILTER COVER | 1 | More Info |
| 35 | KM0403450-35 | SCREW M5*14 | 14 | More Info |
| 36 | KM0403450-36 | CYLINDER COVER | 1 | More Info |
| 37 | KM0403450-37 | STARTER COMP. (NORMAL TYPE) | 1 | More Info |
| 37A | KM0403450-37A | STARTER COMP. (E-STARTER TYPE) | 1 | More Info |
| 38 | KM0403450-38 | FAN COVER | 1 | More Info |
| 39 | KM0403450-39 | NUT M8 | 3 | More Info |
| 04 | KM0403450-04 | SNAP RING | 2 | More Info |
| 40 | KM0403450-40 | FLYWHEEL COMP. | 1 | More Info |
| 41 | KM0403450-41 | SCREW | 2 | More Info |
| 42 | KM0403450-42 | CLAW | 2 | More Info |
| 43 | KM0403450-43 | TORSIONAL SPRING | 2 | More Info |
| 44 | KM0403450-44 | DUST-PROOF CAP | 1 | More Info |
| 45 | KM0403450-45 | IGNITION CAP | 1 | More Info |
| 46 | KM0403450-46 | IGNITION SPRING | 1 | More Info |
| 47 | KM0403450-47 | IGNITION COIL | 1 | More Info |
| 48 | KM0403450-48 | IGNITION COIL COMP. | 1 | More Info |
| 49 | KM0403450-49 | SCREW M4*6 | 2 | More Info |
| 05 | KM0403450-05 | PISTON PIN | 1 | More Info |
| 50 | KM0403450-50 | PRESSING PLATE | 1 | More Info |
| 51 | KM0403450-51 | SCREW M5*30 | 5 | More Info |
| 52 | KM0403450-52 | OIL SEAL 15 35 5 | 1 | More Info |
| 53 | KM0403450-53 | CIRCLIP | 1 | More Info |
| 54 | KM0403450-54 | BEARING 6202 | 2 | More Info |
| 55 | KM0403450-55 | OIL TANK CAP | 1 | More Info |
| 56 | KM0403450-56 | OIL TANK CAP O RING | 1 | More Info |
| 57 | KM0403450-57 | RUBBER CUSHION PLUG | 5 | More Info |
| 58 | KM0403450-58 | SCREW ST4.8*13 | 8 | More Info |
| 59 | KM0403450-59 | RUBBER CUSHION (SHORT) | 3 | More Info |
| 06 | KM0403450-06 | PISTON | 1 | More Info |
| 60 | KM0403450-60 | CRANK CASE (LEFT) | 1 | More Info |
| 61 | KM0403450-61 | RUBBER CUSHION A | 1 | More Info |
| 62 | KM0403450-62 | RUBBER CUSHION B | 1 | More Info |
| 63 | KM0403450-63 | CARBURETOR DUST-PROOF PLUG | 1 | More Info |
| 64 | KM0403450-64 | CRANK CASE GASKET | 1 | More Info |
| 65 | KM0403450-65 | STEEL WIRE | 1 | More Info |
| 66 | KM0403450-66 | CRANK CASE DUST-PROOF PLUG | 1 | More Info |
| 67 | KM0403450-67 | CRANK CASE (RIGHT) | 1 | More Info |
| 68 | KM0403450-68 | PIN 5*10 | 3 | More Info |
| 69 | KM0403450-69 | DENTIFORM PLATE | 1 | More Info |
| 07 | KM0403450-07 | NEEDLE BEARING SNAP RING | 2 | More Info |
| 70 | KM0403450-70 | CARBURETOR SUPPORTOR GASKET | 1 | More Info |
| 71 | KM0403450-71 | STUD | 2 | More Info |
| 72 | KM0403450-72 | OIL FILTER | 1 | More Info |
| 73 | KM0403450-73 | OIL PIPE | 1 | More Info |
| 74 | KM0403450-74 | OIL SEAL 15 28 5 | 1 | More Info |
| 75 | KM0403450-75 | RUBBER CUSHION C | 1 | More Info |
| 76 | KM0403450-76 | AIR CHECK VALVE | 1 | More Info |
| 77 | KM0403450-77 | SPONGE | 1 | More Info |
| 78 | KM0403450-78 | SNAP RING | 1 | More Info |
| 79 | KM0403450-79 | RUBBER CUSHION D | 1 | More Info |
| 08 | KM0403450-08 | NEEDLE BEARING | 1 | More Info |
| 80 | KM0403450-80 | CHOKE ROD RING | 1 | More Info |
| 81 | KM0403450-81 | CHOKE ROD | 1 | More Info |
| 82 | KM0403450-82 | TURRIFORM SPRING | 1 | More Info |
| 83 | KM0403450-83 | TURRIFORM SPRING BASE | 1 | More Info |
| 84 | KM0403450-84 | CHAIN CATCHER | 1 | More Info |
| 85 | KM0403450-85 | OIL PUMP | 1 | More Info |
| 86 | KM0403450-86 | OIL OUTLET PIPE | 1 | More Info |
| 87 | KM0403450-87 | SCREW M4*12 | 5 | More Info |
| 88 | KM0403450-88 | WORM | 1 | More Info |
| 89 | KM0403450-89 | OIL PUMP COVER | 1 | More Info |
| 09 | KM0403450-09 | CRANK SHAFT | 1 | More Info |
| 90 | KM0403450-90 | CLUTCH NEEDLE BEARING | 1 | More Info |
| 91 | KM0403450-91 | RIM SPROCKET | 1 | More Info |
| 92 | KM0403450-92 | CLUTCH DRUM | 1 | More Info |
| 93 | KM0403450-93 | WASHER | 1 | More Info |
| 94 | KM0403450-94 | PRESSING PLATE | 1 | More Info |
| 95 | KM0403450-95 | SCREW M4*10 | 1 | More Info |
| 96 | KM0403450-96 | CLUTCH EXPANDER SHOE | 3 | More Info |
| 97 | KM0403450-97 | CLUTCH EXPANDER HOLDER | 1 | More Info |
| 98 | KM0403450-98 | CLUTCH EXPANDER SPRING | 1 | More Info |
| 99 | KM0403450-99 | CLUTCH EXPANDER COMP. | 1 | More Info |
