KNK Art No.: KM0403260
25.4CC GASOLINE CHAIN SAW
Engine/Bore: 25.4cc/34mm*28mm
Power: 0.9kw/1.2HP
Fuel consumption: 560g/kwh
Spur Sprocket: Spur 6 teeth
Bar & chain: 3/8"x 0.050"(40links=10")
N.W./G.W: 3.5/5.3kgs
20'FCL: 1200PCS
CHINA CARB/CHAIN/BAR
Power: 0.9kw/1.2HP
Fuel consumption: 560g/kwh
Spur Sprocket: Spur 6 teeth
Bar & chain: 3/8"x 0.050"(40links=10")
N.W./G.W: 3.5/5.3kgs
20'FCL: 1200PCS
CHINA CARB/CHAIN/BAR
Product Net Weight
3500g ≈ 3.5 kgs ≈ 123.46oz ≈ 7.72lbs
Fit For Model (Replacement Parts)
Related Brands (Replacement Parts)
Related Categories
↘︎SPARE PARTS LIST
| No. | KNK Art No. | Description | Qty | Button |
|---|
| 01 | KM0403250-01 | ENGINE ASSY. | 1 | More Info |
| 10 | KM0403250-10 | OIL SEAL 12*28*6 | 1 | More Info |
| 11 | KM0403250-11 | OIL SEAL 12*22*4.5 | 1 | More Info |
| 12 | KM0403250-12 | CYLINDER | 1 | More Info |
| 13 | KM0403250-13 | CYLINDER CAP | 1 | More Info |
| 14 | KM0403250-14 | SCREW M5*20 | 4 | More Info |
| 19 | KM0403250-19 | COPPER RING | 1 | More Info |
| 02 | KM0403250-02 | CRANK SHAFT | 1 | More Info |
| 20 | KM0403250-20 | INTAKE PIPE | 1 | More Info |
| 21 | KM0403250-21 | SCREW M4*12 | 2 | More Info |
| 22 | KM0403250-22 | SPARK PLUG | 1 | More Info |
| 23 | KM0403250-23 | KEY | 1 | More Info |
| 24 | KM0403250-24 | FLYWHEEL ASSY. | 1 | More Info |
| 25 | KM0403250-25 | NUT M8*1 | 1 | More Info |
| 03 | KM0403250-03 | NEEDLE BEARING | 1 | More Info |
| 04 | KM0403250-04 | RING SNAP | 2 | More Info |
| 05 | KM0403250-05 | PISTON PIN | 1 | More Info |
| 06 | KM0403250-06 | RING SNAP | 2 | More Info |
| 07 | KM0403250-07 | PISTON | 1 | More Info |
| 08 | KM0403250-08 | PISTON RING | 1 | More Info |
| 09 | KM0403250-09 | BEARING 6001 | 2 | More Info |
| 26 | KM0403250-26 | IGNITION PAD | 2 | More Info |
| 27 | KM0403250-27 | IGNITION COIL | 1 | More Info |
| 28 | KM0403250-28 | SCREW M4*20 | 2 | More Info |
| 29 | KM0403250-29 | WIRE (COIL) | 1 | More Info |
| 30 | KM0403250-30 | MUFFLER GASKET | 1 | More Info |
| 31 | KM0403250-31 | MUFFLER | 1 | More Info |
| 32 | KM0403250-32 | MUFFLER SHIELD | 1 | More Info |
| 33 | KM0403250-33 | SCREW M5*45 | 2 | More Info |
| 34 | KM0403250-34 | WASHER | 1 | More Info |
| 35 | KM0403250-35 | OIL FILTER ASSY. | 1 | More Info |
| 37 | KM0403250-37 | OIL FILTER HEAD | 1 | More Info |
| 38 | KM0403250-38 | OIL FILTER HOSE | 1 | More Info |
| 40 | KM0403250-40 | OIL PUMP | 1 | More Info |
| 41 | KM0403250-41 | GEAR WORM | 1 | More Info |
| 42 | KM0403250-42 | SCREW M4*14 | 2 | More Info |
| 43 | KM0403250-43 | OIL OUTLET HOSE | 1 | More Info |
| 44 | KM0403250-44 | OIL PUMP COVER | 1 | More Info |
| 45 | KM0403250-45 | SCREW ST4.2*13 | 2 | More Info |
| 47 | KM0403250-47 | NEEDLE BEARING | 1 | More Info |
| 48 | KM0403250-48 | CLUTCH DRUM 3/8 6T (FOR250/260) | 1 | More Info |
| 48A | KM0403250-48A | CLUTCH DRUM 1/4 8T (FOR251) | 1 | More Info |
| 49 | KM0403250-49 | WASHER | 1 | More Info |
| 50 | KM0403250-50 | EXPANDER SHOE | 2 | More Info |
| 51 | KM0403250-51 | EXPANDER SPRING | 2 | More Info |
| 52 | KM0403250-52 | EXPANDER SUPPORTOR | 1 | More Info |
| 53 | KM0403250-53 | FUEL AND OIL TANK ASSY. | 1 | More Info |
| 54 | KM0403250-54 | FUEL AND OIL TANK | 1 | More Info |
| 55 | KM0403250-55 | RUBBER CUSHION | 1 | More Info |
| 56 | KM0403250-56 | SCREW ST4.8*13 | 1 | More Info |
| 57 | KM0403250-57 | RUBBER CUSHION CAP | 1 | More Info |
| 58 | KM0403250-58 | HANGER | 1 | More Info |
| 59 | KM0403250-59 | SCREW ST4.5*12 | 4 | More Info |
| 63 | KM0403250-63 | SCREW ST4.3*10 | 2 | More Info |
| 64 | KM0403250-64 | PLATE BAR | 1 | More Info |
| 65 | KM0403250-65 | CHAIN CATCHER | 1 | More Info |
| 66 | KM0403250-66 | SCREW ST5.5*15 | 1 | More Info |
| 67 | KM0403250-67 | PRIMER BULB | 1 | More Info |
| 68 | KM0403250-68 | HOSE | 1 | More Info |
| 69 | KM0403250-69 | HOSE CONNECTOR | 1 | More Info |
| 70 | KM0403250-70 | FUEL FILTER ASSY. | 1 | More Info |
| 71 | KM0403250-71 | FUEL FILTER HEAD | 1 | More Info |
| 74 | KM0403250-74 | FUEL FILTER HOSE | 1 | More Info |
| 75 | KM0403250-75 | HOSE CONNECTOR | 1 | More Info |
| 76 | KM0403250-76 | BREATHER SEAT | 1 | More Info |
| 77 | KM0403250-77 | BREATHER | 1 | More Info |
| 78 | KM0403250-78 | STOP | 1 | More Info |
| 79 | KM0403250-79 | SCREW ST5*12 | 2 | More Info |
| 80 | KM0403250-80 | TANK CAP ASSY. | 2 | More Info |
| 81 | KM0403250-81 | TANK CAP | 2 | More Info |
| 82 | KM0403250-82 | O RING | 2 | More Info |
| 83 | KM0403250-83 | CAP CHAIN | 2 | More Info |
| 84 | KM0403250-84 | WIRE (GROUND) | 1 | More Info |
| 85 | KM0403250-85 | SCREW M5*16 | 5 | More Info |
| 86 | KM0403250-86 | GASKET | 1 | More Info |
| 87 | KM0403250-87 | PLASTIC COVER | 1 | More Info |
| 88 | KM0403250-88 | SCREW ST4.2*16 | 2 | More Info |
| 89 | KM0403250-89 | REAR HANDLE ASSY. | 1 | More Info |
| 90 | KM0403250-90 | REAR HADLE | 1 | More Info |
| 92 | KM0403250-92 | RUBBER CUSHION | 1 | More Info |
| 93 | KM0403250-93 | SCREWM ST4.8*19 | 1 | More Info |
| 94 | KM0403250-94 | RUBBER CUSHION CAP | 1 | More Info |
| 95 | KM0403250-95 | TORSIONAL SPRING | 1 | More Info |
| 96 | KM0403250-96 | TRIGGER | 1 | More Info |
| 97 | KM0403250-97 | COTTER PIN 5*25 | 1 | More Info |
| 98 | KM0403250-98 | STOP SWITCH | 1 | More Info |
| 99 | KM0403250-99 | HOSE | 2 | More Info |
| 101 | KM0403250-101 | THROTTLE STEEL WIRE | 1 | More Info |
| 102 | KM0403250-102 | LEVER SAFETY TRIGGER | 1 | More Info |
| 103 | KM0403250-103 | REAR HANDLE COVER (FOR250/251) | 1 | More Info |
| 103A | KM0403250-103A | REAR HANDLE COVER (FOR260) | 1 | More Info |
| 104 | KM0403250-104 | SCREW ST4.2*16 | 1 | More Info |
| 105 | KM0403250-105 | CARBURETOR SPONGE | 1 | More Info |
| 106 | KM0403250-106 | CARBURETOR | 1 | More Info |
| 107 | KM0403250-107 | GROMMET CHOKE KNOB | 1 | More Info |
| 108 | KM0403250-108 | CHOKE KNOB | 1 | More Info |
| 109 | KM0403250-109 | AIR FILTER A | 1 | More Info |
| 110 | KM0403250-110 | AIR FILTER PLATE | 1 | More Info |
| 111 | KM0403250-111 | SCREW M5*45 | 2 | More Info |
| 112 | KM0403250-112 | AIR FILTER SPONGE | 1 | More Info |
| 113 | KM0403250-113 | AIF FILTER B | 1 | More Info |
| 114 | KM0403250-114 | AIR FILTER COVER （FOR250/251) | 1 | More Info |
| 114A | KM0403250-114A | AIR FILTER COVER （FOR260) | 1 | More Info |
| 115 | KM0403250-115 | AIR FILTER KNOB | 1 | More Info |
| 116 | KM0403250-116 | STARTER ASSY. (FOR250/251) | 1 | More Info |
| 116A | KM0403250-116A | STARTER ASSY. (FOR260) | 1 | More Info |
| 117 | KM0403250-117 | STARTER HOUSING (FOR250/251) | 1 | More Info |
| 117A | KM0403250-117A | STARTER HOUSING (FOR260) | 1 | More Info |
| 118 | KM0403250-118 | BAFFLE FAN (FOR250/251) | 1 | More Info |
| 118A | KM0403250-118A | BAFFLE FAN (FOR260) | 1 | More Info |
| 119 | KM0403250-119 | SCREW | 1 | More Info |
| 120 | KM0403250-120 | SUPPORT HOSE AIR | 1 | More Info |
| 121 | KM0403250-121 | COIL SPRING | 1 | More Info |
| 122 | KM0403250-122 | COIL SPRING SEAT | 1 | More Info |
| 123 | KM0403250-123 | ROPE REEL | 1 | More Info |
| 124 | KM0403250-124 | ROPE | 1 | More Info |
| 125 | KM0403250-125 | WASHER | 1 | More Info |
| 126 | KM0403250-126 | SCREW ST4.8*13 | 1 | More Info |
| 128 | KM0403250-128 | HANDLE | 1 | More Info |
| 131 | KM0403250-131 | SCREW ST4.3*16 | 5 | More Info |
| 132 | KM0403250-132 | BALE HANDLE | 1 | More Info |
| 133 | KM0403250-133 | NYLON STRAP | 1 | More Info |
| 134 | KM0403250-134 | SCREW ST4.8*13 | 1 | More Info |
| 135 | KM0403250-135 | RUBBER CUSHION | 1 | More Info |
| 136 | KM0403250-136 | SCREW ST4.8*16 | 1 | More Info |
| 137 | KM0403250-137 | RUBBER CUSHION CAP | 1 | More Info |
| 139 | KM0403250-139 | SCREW ST5*16 | 2 | More Info |
| 140 | KM0403250-140 | BRAKE ASSY. | 1 | More Info |
| 141 | KM0403250-141 | BRAKE HOUSING | 1 | More Info |
| 142 | KM0403250-142 | SPRING LEVERAGE | 1 | More Info |
| 143 | KM0403250-143 | SPRING SUPPORTOR | 1 | More Info |
| 144 | KM0403250-144 | LEVERAGE BRAKE | 1 | More Info |
| 145 | KM0403250-145 | TORSIONAL SPRING | 1 | More Info |
| 146 | KM0403250-146 | PIN | 1 | More Info |
| 147 | KM0403250-147 | LEVERAGE | 1 | More Info |
| 148 | KM0403250-148 | PIN | 1 | More Info |
| 149 | KM0403250-149 | SCREW M5*30 | 1 | More Info |
| 150 | KM0403250-150 | NUT M5 | 1 | More Info |
| 151 | KM0403250-151 | TORSIONAL SPRING | 1 | More Info |
| 152 | KM0403250-152 | SPRING PUSHER ASSY. | 1 | More Info |
| 157 | KM0403250-157 | BRAKE PLATE | 1 | More Info |
| 158 | KM0403250-158 | BRAKE BAND | 1 | More Info |
| 159 | KM0403250-159 | SPRING | 1 | More Info |
| 160 | KM0403250-160 | COVER | 1 | More Info |
| 161 | KM0403250-161 | SCREW ST4.2*13 | 3 | More Info |
| 162 | KM0403250-162 | BAR TENSIONER | 1 | More Info |
| 163 | KM0403250-163 | BAR PLATE | 1 | More Info |
| 164 | KM0403250-164 | SCREW ST4.2*13 | 3 | More Info |
| 165 | KM0403250-165 | INTAKE GASKET | 1 | More Info |
| 166 | KM0403250-166 | IGNITION SPRING | 1 | More Info |
| 167 | KM0403250-167 | IGNITION CAP | 1 | More Info |
| 168 | KM0403250-168 | IGNITION COIL ASSY. | 1 | More Info |
| 169 | KM0403250-169 | CLUTCH EXPANDER ASSY. | 1 | More Info |
| 170 | KM0403250-170 | OIL PUMP SPONGE | 1 | More Info |
| 171 | KM0403250-171 | WASHER | 1 | More Info |
| 172 | KM0403250-172 | KNOB | 1 | More Info |
| 173 | KM0403250-173 | NUT M8 | 1 | More Info |
| 174 | KM0403250-174 | DENTIFORM PLATE | 1 | More Info |
| 175 | KM0403250-175 | SCREW ST5*12 | 2 | More Info |
| 176 | KM0403250-176 | AIR CHECK VALVE | 1 | More Info |
| 177 | KM0403250-177 | SPONGE | 1 | More Info |
| 178 | KM0403250-178 | SANP RING | 1 | More Info |
| 179 | KM0403250-179 | WASHER | 1 | More Info |
| 180 | KM0403250-180 | PIN | 1 | More Info |
| 181 | KM0403250-181 | SAW CHAIN 3/8 (FOR250/260) | 1 | More Info |
| 181A | KM0403250-181A | SAW CHAIN 1/4 (FOR251) | 1 | More Info |
| 182 | KM0403250-182 | GUIDE BAR 3/8 (FOR250/260) | 1 | More Info |
| 182A | KM0403250-182A | CARVING BAR (FOR251) | 1 | More Info |
| 183 | KM0403250-183 | GUIDE BAR PROTECTOR | 1 | More Info |
| 184 | KM0403250-184 | PLATE | 1 | More Info |
| 185 | KM0403250-185 | CYLINDER PISTON KIT | 1 | More Info |
| No. | KNK Art No. | Description | Qty | Button |
|---|
| 01 | KM0403251-01 | ENGINE ASSY. | 1 | More Info |
| 02 | KM0403251-02 | CRANK SHAFT | 1 | More Info |
| 03 | KM0403251-03 | NEEDLE BEARING | 1 | More Info |
| 04 | KM0403251-04 | RING SNAP | 2 | More Info |
| 05 | KM0403251-05 | PISTON PIN | 1 | More Info |
| 06 | KM0403251-06 | RING SNAP | 2 | More Info |
| 07 | KM0403251-07 | PISTON | 1 | More Info |
| 08 | KM0403251-08 | PISTON RING | 1 | More Info |
| 09 | KM0403251-09 | BEARING 6001 | 2 | More Info |
| 10 | KM0403251-10 | OIL SEAL 12*28*6 | 1 | More Info |
| 101 | KM0403251-101 | THROTTLE STEEL WIRE | 1 | More Info |
| 102 | KM0403251-102 | LEVER SAFETY TRIGGER | 1 | More Info |
| 103 | KM0403251-103 | REAR HANDLE COVER (FOR250/251) | 1 | More Info |
| 103A | KM0403251-103A | REAR HANDLE COVER (FOR260) | 1 | More Info |
| 104 | KM0403251-104 | SCREW ST4.2*16 | 1 | More Info |
| 105 | KM0403251-105 | CARBURETOR SPONGE | 1 | More Info |
| 106 | KM0403251-106 | CARBURETOR | 1 | More Info |
| 107 | KM0403251-107 | GROMMET CHOKE KNOB | 1 | More Info |
| 108 | KM0403251-108 | CHOKE KNOB | 1 | More Info |
| 109 | KM0403251-109 | AIR FILTER A | 1 | More Info |
| 11 | KM0403251-11 | OIL SEAL 12*22*4.5 | 1 | More Info |
| 110 | KM0403251-110 | AIR FILTER PLATE | 1 | More Info |
| 111 | KM0403251-111 | SCREW M5*45 | 2 | More Info |
| 112 | KM0403251-112 | AIR FILTER SPONGE | 1 | More Info |
| 113 | KM0403251-113 | AIF FILTER B | 1 | More Info |
| 114 | KM0403251-114 | AIR FILTER COVER （FOR250/251) | 1 | More Info |
| 114A | KM0403251-114A | AIR FILTER COVER （FOR260) | 1 | More Info |
| 115 | KM0403251-115 | AIR FILTER KNOB | 1 | More Info |
| 116 | KM0403251-116 | STARTER ASSY. (FOR250/251) | 1 | More Info |
| 116A | KM0403251-116A | STARTER ASSY. (FOR260) | 1 | More Info |
| 117 | KM0403251-117 | STARTER HOUSING (FOR250/251) | 1 | More Info |
| 117A | KM0403251-117A | STARTER HOUSING (FOR260) | 1 | More Info |
| 118 | KM0403251-118 | BAFFLE FAN (FOR250/251) | 1 | More Info |
| 118A | KM0403251-118A | BAFFLE FAN (FOR260) | 1 | More Info |
| 119 | KM0403251-119 | SCREW | 1 | More Info |
| 12 | KM0403251-12 | CYLINDER | 1 | More Info |
| 120 | KM0403251-120 | SUPPORT HOSE AIR | 1 | More Info |
| 121 | KM0403251-121 | COIL SPRING | 1 | More Info |
| 122 | KM0403251-122 | COIL SPRING SEAT | 1 | More Info |
| 123 | KM0403251-123 | ROPE REEL | 1 | More Info |
| 124 | KM0403251-124 | ROPE | 1 | More Info |
| 125 | KM0403251-125 | WASHER | 1 | More Info |
| 126 | KM0403251-126 | SCREW ST4.8*13 | 1 | More Info |
| 128 | KM0403251-128 | HANDLE | 1 | More Info |
| 13 | KM0403251-13 | CYLINDER CAP | 1 | More Info |
| 131 | KM0403251-131 | SCREW ST4.3*16 | 5 | More Info |
| 132 | KM0403251-132 | BALE HANDLE | 1 | More Info |
| 133 | KM0403251-133 | NYLON STRAP | 1 | More Info |
| 134 | KM0403251-134 | SCREW ST4.8*13 | 1 | More Info |
| 135 | KM0403251-135 | RUBBER CUSHION | 1 | More Info |
| 136 | KM0403251-136 | SCREW ST4.8*16 | 1 | More Info |
| 137 | KM0403251-137 | RUBBER CUSHION CAP | 1 | More Info |
| 139 | KM0403251-139 | SCREW ST5*16 | 2 | More Info |
| 14 | KM0403251-14 | SCREW M5*20 | 4 | More Info |
| 140 | KM0403251-140 | BRAKE ASSY. | 1 | More Info |
| 141 | KM0403251-141 | BRAKE HOUSING | 1 | More Info |
| 142 | KM0403251-142 | SPRING LEVERAGE | 1 | More Info |
| 143 | KM0403251-143 | SPRING SUPPORTOR | 1 | More Info |
| 144 | KM0403251-144 | LEVERAGE BRAKE | 1 | More Info |
| 145 | KM0403251-145 | TORSIONAL SPRING | 1 | More Info |
| 146 | KM0403251-146 | PIN | 1 | More Info |
| 147 | KM0403251-147 | LEVERAGE | 1 | More Info |
| 148 | KM0403251-148 | PIN | 1 | More Info |
| 149 | KM0403251-149 | SCREW M5*30 | 1 | More Info |
| 150 | KM0403251-150 | NUT M5 | 1 | More Info |
| 151 | KM0403251-151 | TORSIONAL SPRING | 1 | More Info |
| 152 | KM0403251-152 | SPRING PUSHER ASSY. | 1 | More Info |
| 157 | KM0403251-157 | BRAKE PLATE | 1 | More Info |
| 158 | KM0403251-158 | BRAKE BAND | 1 | More Info |
| 159 | KM0403251-159 | SPRING | 1 | More Info |
| 160 | KM0403251-160 | COVER | 1 | More Info |
| 161 | KM0403251-161 | SCREW ST4.2*13 | 3 | More Info |
| 162 | KM0403251-162 | BAR TENSIONER | 1 | More Info |
| 163 | KM0403251-163 | BAR PLATE | 1 | More Info |
| 164 | KM0403251-164 | SCREW ST4.2*13 | 3 | More Info |
| 165 | KM0403251-165 | INTAKE GASKET | 1 | More Info |
| 166 | KM0403251-166 | IGNITION SPRING | 1 | More Info |
| 167 | KM0403251-167 | IGNITION CAP | 1 | More Info |
| 168 | KM0403251-168 | IGNITION COIL ASSY. | 1 | More Info |
| 169 | KM0403251-169 | CLUTCH EXPANDER ASSY. | 1 | More Info |
| 170 | KM0403251-170 | OIL PUMP SPONGE | 1 | More Info |
| 171 | KM0403251-171 | WASHER | 1 | More Info |
| 172 | KM0403251-172 | SCREW M5*15 | 1 | More Info |
| 173 | KM0403251-173 | NUT M8 | 1 | More Info |
| 174 | KM0403251-174 | DENTIFORM PLATE | 1 | More Info |
| 175 | KM0403251-175 | SCREW ST5*12 | 2 | More Info |
| 176 | KM0403251-176 | AIR CHECK VALVE | 1 | More Info |
| 177 | KM0403251-177 | SPONGE | 1 | More Info |
| 178 | KM0403251-178 | SANP RING | 1 | More Info |
| 179 | KM0403251-179 | WASHER | 1 | More Info |
| 180 | KM0403251-180 | PIN | 1 | More Info |
| 181 | KM0403251-181 | SAW CHAIN 3/8 (FOR250/260) | 1 | More Info |
| 181A | KM0403251-181A | SAW CHAIN 1/4 (FOR251) | 1 | More Info |
| 182 | KM0403251-182 | GUIDE BAR 3/8 (FOR250/260) | 1 | More Info |
| 182A | KM0403251-182A | CARVING BAR (FOR251) | 1 | More Info |
| 183 | KM0403251-183 | GUIDE BAR PROTECTOR | 1 | More Info |
| 184 | KM0403251-184 | CYLINDER PISTON KIT | 1 | More Info |
| 19 | KM0403251-19 | COPPER RING | 1 | More Info |
| 20 | KM0403251-20 | INTAKE PIPE | 1 | More Info |
| 21 | KM0403251-21 | SCREW M4*12 | 2 | More Info |
| 22 | KM0403251-22 | SPARK PLUG | 1 | More Info |
| 23 | KM0403251-23 | KEY | 1 | More Info |
| 24 | KM0403251-24 | FLYWHEEL ASSY. | 1 | More Info |
| 25 | KM0403251-25 | NUT M8*1 | 1 | More Info |
| 26 | KM0403251-26 | IGNITION PAD | 2 | More Info |
| 27 | KM0403251-27 | IGNITION COIL | 1 | More Info |
| 28 | KM0403251-28 | SCREW M4*20 | 2 | More Info |
| 29 | KM0403251-29 | WIRE (COIL) | 1 | More Info |
| 30 | KM0403251-30 | MUFFLER GASKET | 1 | More Info |
| 31 | KM0403251-31 | MUFFLER | 1 | More Info |
| 32 | KM0403251-32 | MUFFLER SHIELD | 1 | More Info |
| 33 | KM0403251-33 | SCREW M5*45 | 2 | More Info |
| 34 | KM0403251-34 | WASHER | 1 | More Info |
| 35 | KM0403251-35 | OIL FILTER ASSY. | 1 | More Info |
| 37 | KM0403251-37 | OIL FILTER HEAD | 1 | More Info |
| 38 | KM0403251-38 | OIL FILTER HOSE | 1 | More Info |
| 40 | KM0403251-40 | OIL PUMP | 1 | More Info |
| 41 | KM0403251-41 | GEAR WORM | 1 | More Info |
| 42 | KM0403251-42 | SCREW M4*14 | 2 | More Info |
| 43 | KM0403251-43 | OIL OUTLET HOSE | 1 | More Info |
| 44 | KM0403251-44 | OIL PUMP COVER | 1 | More Info |
| 45 | KM0403251-45 | SCREW ST4.2*13 | 2 | More Info |
| 47 | KM0403251-47 | NEEDLE BEARING | 1 | More Info |
| 48 | KM0403251-48 | CLUTCH DRUM 3/8 6T (FOR250/260) | 1 | More Info |
| 48A | KM0403251-48A | CLUTCH DRUM 1/4 8T (FOR251) | 1 | More Info |
| 49 | KM0403251-49 | WASHER | 1 | More Info |
| 50 | KM0403251-50 | EXPANDER SHOE | 2 | More Info |
| 51 | KM0403251-51 | EXPANDER SPRING | 2 | More Info |
| 52 | KM0403251-52 | EXPANDER SUPPORTOR | 1 | More Info |
| 53 | KM0403251-53 | FUEL AND OIL TANK ASSY. | 1 | More Info |
| 54 | KM0403251-54 | FUEL AND OIL TANK | 1 | More Info |
| 55 | KM0403251-55 | RUBBER CUSHION | 1 | More Info |
| 56 | KM0403251-56 | SCREW ST4.8*13 | 1 | More Info |
| 57 | KM0403251-57 | RUBBER CUSHION CAP | 1 | More Info |
| 58 | KM0403251-58 | HANGER | 1 | More Info |
| 59 | KM0403251-59 | SCREW ST4.5*12 | 1 | More Info |
| 63 | KM0403251-63 | SCREW ST4.3*10 | 2 | More Info |
| 64 | KM0403251-64 | PLATE BAR | 1 | More Info |
| 65 | KM0403251-65 | CHAIN CATCHER | 1 | More Info |
| 66 | KM0403251-66 | SCREW ST5.5*15 | 1 | More Info |
| 67 | KM0403251-67 | PRIMER BULB | 1 | More Info |
| 68 | KM0403251-68 | HOSE | 1 | More Info |
| 69 | KM0403251-69 | HOSE CONNECTOR | 1 | More Info |
| 70 | KM0403251-70 | FUEL FILTER ASSY. | 1 | More Info |
| 71 | KM0403251-71 | FUEL FILTER HEAD | 1 | More Info |
| 74 | KM0403251-74 | FUEL FILTER HOSE | 1 | More Info |
| 75 | KM0403251-75 | HOSE CONNECTOR | 1 | More Info |
| 76 | KM0403251-76 | BREATHER SEAT | 1 | More Info |
| 77 | KM0403251-77 | BREATHER | 1 | More Info |
| 78 | KM0403251-78 | STOP | 1 | More Info |
| 79 | KM0403251-79 | SCREW ST5*12 | 2 | More Info |
| 80 | KM0403251-80 | TANK CAP ASSY. | 2 | More Info |
| 81 | KM0403251-81 | TANK CAP | 2 | More Info |
| 82 | KM0403251-82 | O RING | 2 | More Info |
| 83 | KM0403251-83 | CAP CHAIN | 2 | More Info |
| 84 | KM0403251-84 | WIRE (GROUND) | 1 | More Info |
| 85 | KM0403251-85 | SCREW M5*16 | 5 | More Info |
| 86 | KM0403251-86 | GASKET | 1 | More Info |
| 87 | KM0403251-87 | PLASTIC COVER | 1 | More Info |
| 88 | KM0403251-88 | SCREW ST4.2*16 | 2 | More Info |
| 89 | KM0403251-89 | REAR HANDLE ASSY. | 1 | More Info |
| 90 | KM0403251-90 | REAR HADLE | 1 | More Info |
| 92 | KM0403251-92 | RUBBER CUSHION | 1 | More Info |
| 93 | KM0403251-93 | SCREWM ST4.8*19 | 1 | More Info |
| 94 | KM0403251-94 | RUBBER CUSHION CAP | 1 | More Info |
| 95 | KM0403251-95 | TORSIONAL SPRING | 1 | More Info |
| 96 | KM0403251-96 | TRIGGER | 1 | More Info |
| 97 | KM0403251-97 | COTTER PIN 5*25 | 1 | More Info |
| 98 | KM0403251-98 | STOP SWITCH | 1 | More Info |
| 99 | KM0403251-99 | HOSE | 2 | More Info |
Can’t find your answer?
Recently viewed
Last seen items
