KNK Art No.: KM1E34F
2 Stroke 25.4CC GASOLINE ENGINE
Displacement: 25.4cc/34x28mm
Max power: 0.75kw/1.1HP
Fuel consumption: ≤740g/kwh
Fuel tank: 0.75L
N.W.: 2.7kgs
packing: 27x24x30cm
20'FCL: 2000PCS
Max power: 0.75kw/1.1HP
Fuel consumption: ≤740g/kwh
Fuel tank: 0.75L
N.W.: 2.7kgs
packing: 27x24x30cm
20'FCL: 2000PCS
Product Net Weight
2700g ≈ 2.7 kgs ≈ 95.24oz ≈ 5.95lbs
Fit For Model (Replacement Parts)
Related Brands (Replacement Parts)
Related Categories
↘︎SPARE PARTS LIST
| No. | KNK Art No. | Description | Qty | Button |
|---|
| 1 | 17.1-225 | SCREW | 1 | More Info |
| 1B | KM1E34F-1B | CLEANER OUTSIDE COVER | 1 | More Info |
| 2 | 17.2-225 | CLEANER OUTSIDE COVER | 1 | More Info |
| 2B | KM1E34F-2B | CLEANER ELEMENT | 2 | More Info |
| 3 | 17-201 | CLEANER ELEMENT | 1 | More Info |
| 3A | 17-225 | AIR FILTER COMP. | 1 | More Info |
| 3B | KM1E34F-3B | METAL NET | 1 | More Info |
| 3C | KM1E34F-3C | AIR FILTER | COMP. | More Info |
| 4 | KM1E34F-4 | SCREW M5*55 | 2 | More Info |
| 4B | KM1E34F-4B | METAL PLATE | 1 | More Info |
| 5 | 17.3-225 | CLEANER INSIDE COVER | 1 | More Info |
| 5B | KM1E34F-5B | ROD | 1 | More Info |
| 6 | KM1E34F-6 | SCREW ST4.2*12-F-H | 1 | More Info |
| 6B | KM1E34F-6B | SCREW | 2 | More Info |
| 7 | 17.4-225 | CHOKE | 1 | More Info |
| 7B | KM1E34F-7B | CLEANER INSIDE COVER | 1 | More Info |
| 8 | 17.5-225 | CHOKE HANDLE | 1 | More Info |
| 9 | 36-201 | CARBURETOR | 1 | More Info |
| 10 | 15.2-203 | GASKET | 1 | More Info |
| 11 | KM1E34F-11 | SCREW M5*20 | 2 | More Info |
| 12 | 16-201 | INLET MANIFOLD | 1 | More Info |
| 13 | 15.3-203 | INLET MANIFOLD GASKET | 1 | More Info |
| 14 | 12.1-01 | PIN B3*10 | 4 | More Info |
| 15 | KM1E34F-15 | SCREW M4*16 | 9 | More Info |
| 16 | 02-201 | FAN COVER | 1 | More Info |
| 17 | 23.3-201 | CLUTCH STEP SCREW | 2 | More Info |
| 18 | 23.3-201B | WASHER | 2 | More Info |
| 19 | 23.1-201 | CLUTCH SHOE | 2 | More Info |
| 19A | 23-201 | CLUTCH COMP. | 1 | More Info |
| 20 | 23.3-201A | WASHER | 2 | More Info |
| 21 | 23.2-201 | CLUTCH SPRING | 1 | More Info |
| 22 | KM1E34F-22 | NUT M8*1 | 1 | More Info |
| 23 | KM1E34F-23 | WASHER 8 | 1 | More Info |
| 24 | KM1E34F-24 | STOP CORD COMP. | 1 | More Info |
| 25 | KM1E34F-25 | PRIMARY CORD GROMMET | 1 | More Info |
| 26 | KM1E34F-26 | MAGNETO STATOR | 1 | More Info |
| 26A | 32-201 | MAGNETO ROTOR | 1 | More Info |
| 26B | 31-201 | IGNITION COIL COMP. | 1 | More Info |
| 27 | KM1E34F-27 | SCREW M5*25 | 4 | More Info |
| 28 | 12-201B | FRONT HALF CRANK CASE | 1 | More Info |
| 29 | KM1E34F-29 | GUIDE PLATE | 1 | More Info |
| 30 | 15.4-203 | CRANK CASE GASKET | 1 | More Info |
| 31 | 27-201 | OIL SEAL 12*22*7 | 2 | More Info |
| 32 | KM1E34F-32 | BEARING 6001/P5 | 2 | More Info |
| 33 | 14.2-201 | KEY | 1 | More Info |
| 34 | 14-201 | CRANK SHAFT COMP. | 1 | More Info |
| 35 | 12-201A | REAR HALF CRANK CASE | 1 | More Info |
| 36 | KM1E34F-36 | STARTER PULLEY | 1 | More Info |
| 37 | KM1E34F-37 | STARTER PAWL SPRING | 1 | More Info |
| 38 | 19.1-201 | STARTER PAWL | 1 | More Info |
| 39 | KM1E34F-39 | SCREW M5*10 | 1 | More Info |
| 40 | 18.2-201 | RECOIL SPRING | 1 | More Info |
| 41 | 18.3-201 | STARTER ROPE REEL | 1 | More Info |
| 42 | KM1E34F-42 | RECOIL STARTER BODY | 1 | More Info |
| 44 | KM1E34F-44 | ROPE | 1 | More Info |
| 45 | 18.1-16 | STARTER HANDLE | 1 | More Info |
| 46 | KM1E34F-46 | PLUG | 1 | More Info |
| 47 | KM1E34F-47 | SCREW M5*14 | 1 | More Info |
| 48 | KM1E34F-48 | COVER | 1 | More Info |
| 49 | 01-201 | CYLINDER COVER | 1 | More Info |
| 50 | KM1E34F-50 | SCREW M4*12 | 1 | More Info |
| 51 | 31.1-201 | PLUG CAP | 1 | More Info |
| 52 | KM1E34F-52 | CLICK SPRING | 1 | More Info |
| 53 | KM1E34F-53 | PLUG COVER | 1 | More Info |
| 54 | 33-202 | SPARK PLUG | 1 | More Info |
| 55 | KM1E34F-55 | SCREW M5*20 | 4 | More Info |
| 58 | 15.5-203 | MUFFLER GASKET | 1 | More Info |
| 59 | 20-201 | MUFFLER COMP. | 1 | More Info |
| 60 | KM1E34F-60 | BOLT | 2 | More Info |
| 61 | KM1E34F-61 | WASHER 5 | 2 | More Info |
| 62 | KM1E34F-62 | NUT M5 | 2 | More Info |
| 63 | 11.3-201 | CYLINDER | 1 | More Info |
| 63A | 11-201 | CYLINDER PISTON KIT | 1 | More Info |
| 64 | 15.1-203 | CYLINDER GASKET | 1 | More Info |
| 65 | 11.1-201 | PISTON RING | 2 | More Info |
| 66 | KM1E34F-66 | PISTON | 1 | More Info |
| 67 | KM1E34F-67 | STOP RING | 2 | More Info |
| 68 | KM1E34F-68 | PISTON PIN | 1 | More Info |
| 69 | 26-201 | NEEDLE BEARING | 1 | More Info |
| 70 | KM1E34F-70 | PISTON PIN CIRCLET | 2 | More Info |
| 71 | KM1E34F-71 | FUEL TANK CAP | 1 | More Info |
| 72 | KM1E34F-72 | O RING | 1 | More Info |
| 73 | KM1E34F-73 | AIRINLET MOUTH | 1 | More Info |
| 74 | KM1E34F-74 | INSIDE COVER | 1 | More Info |
| 75 | KM1E34F-75 | INLET FUEL PIPE | 1 | More Info |
| 76 | KM1E34F-76 | OUTLET FUEL PIPE | 1 | More Info |
| 77 | KM1E34F-77 | PRIMARY CORD GROMMET | 1 | More Info |
| 78 | KM1E34F-78 | FUEL FILTER | 1 | More Info |
| 79 | KM1E34F-79 | FUEL TANK | 1 | More Info |
| 79A | 24-201 | FUEL TANK COMP. | 1 | More Info |
| 80 | KM1E34F-80 | SCREW M5*16 | 1 | More Info |
| 81 | KM1E34F-81 | SCREW M5*16 | 2 | More Info |
| 82 | 19-201 | STARTER PULLEY ASSY. | 1 | More Info |
| 83 | 18-201 | STARTER | 1 | More Info |
| 85 | KM1E34F-85 | LID | 1 | More Info |
| 86 | KM1E34F-86 | CHAIN | 1 | More Info |
| 87 | 24.1-201 | FUEL TANK LID COMP. | 1 | More Info |
| 88 | 25-201 | FUEL TANK PROTECTOR | 1 | More Info |
