KNK Art No.: KM1E33F
2 Stroke 25.6CC GASOLINE ENGINE
Displacement/bore x stroke: 25.6cc/33x30mm
Max power: 0.75kw/1.0HP
Fuel consumption: ≤480g/kwh
Fuel tank: 0.6L
N.W.: 2.4kgs
packing: 26x24x25cm CLUTCH Ø54MM
Max power: 0.75kw/1.0HP
Fuel consumption: ≤480g/kwh
Fuel tank: 0.6L
N.W.: 2.4kgs
packing: 26x24x25cm CLUTCH Ø54MM
Fit For Models.
TU26
Product Net Weight
2400g ≈ 2.4 kgs ≈ 84.66oz ≈ 5.29lbs
Fit For Model (Replacement Parts)
Related Brands (Replacement Parts)
Related Categories
↘︎SPARE PARTS LIST
| No. | KNK Art No. | Description | Qty | Button |
|---|
| 1 | KM1E33F-1 | SCREW | 1 | More Info |
| 2 | KM1E33F-2 | CLEANER OUTSIDE COVER | 1 | More Info |
| 3 | KM1E33F-3 | CLEANER ELEMENT | 1 | More Info |
| 4 | KM1E33F-4 | SCREW M5*55 | 2 | More Info |
| 5 | KM1E33F-5 | CLEANER INSIDE COVER | 1 | More Info |
| 6 | KM1E33F-6 | SCREW ST4.2*12-F-H | 1 | More Info |
| 7 | KM1E33F-7 | CHOKE | 1 | More Info |
| 8 | KM1E33F-8 | CHOKE HANDLE | 1 | More Info |
| 9 | KM1E33F-9 | CARBURETOR | 1 | More Info |
| 10 | KM1E33F-10 | GASKET | 1 | More Info |
| 11 | KM1E33F-11 | SCREW M5*25 | 2 | More Info |
| 12 | KM1E33F-12 | INLET MANIFOLD | 1 | More Info |
| 13 | KM1E33F-13 | INLET MANIFOLD GASKET | 1 | More Info |
| 14 | KM1E33F-14 | PIN B3*8 | 4 | More Info |
| 15 | KM1E33F-15 | SCREW M5*20 | 9 | More Info |
| 16 | KM1E33F-16 | FAN COVER | 1 | More Info |
| 17 | KM1E33F-17 | CLUTCH STEP SCREW | 2 | More Info |
| 18 | KM1E33F-18 | WASHER | 2 | More Info |
| 19 | KM1E33F-19 | CLUTCH SHOE | 2 | More Info |
| 20 | KM1E33F-20 | WASHER | 2 | More Info |
| 21 | KM1E33F-21 | CLUTCH SPRING | 1 | More Info |
| 22 | KM1E33F-22 | NUT M8*1 | 1 | More Info |
| 23 | KM1E33F-23 | WASHER 8 | 1 | More Info |
| 24 | KM1E33F-24 | STOP CORD COMP. | 1 | More Info |
| 25 | KM1E33F-25 | PRIMARY CORD GROMMET | 1 | More Info |
| 26 | KM1E33F-26 | MAGNETO STATOR | 1 | More Info |
| 26A | KM1E33F-26A | MAGNETO ROTOR | 1 | More Info |
| 27 | KM1E33F-27 | SCREW M5*25 | 3 | More Info |
| 28 | KM1E33F-28 | FRONT HALF CRANK CASE | 1 | More Info |
| 29 | KM1E33F-29 | GUIDE PLATE | 1 | More Info |
| 30 | KM1E33F-30 | CRANK CASE GASKET | 1 | More Info |
| 31 | KM1E33F-31 | OIL SEAL 12*22*7 | 1 | More Info |
| 32 | KM1E33F-32 | BEARING 6001/P5 | 2 | More Info |
| 33 | KM1E33F-33 | KEY | 1 | More Info |
| 34 | KM1E33F-34 | CRANK SHAFT COMP. | 1 | More Info |
| 35 | KM1E33F-35 | REAR HALF CRANK CASE | 1 | More Info |
| 36 | KM1E33F-36 | STARTER PULLEY | 1 | More Info |
| 37 | KM1E33F-37 | STARTER PAWL SPRING | 1 | More Info |
| 38 | KM1E33F-38 | STARTER PAWL | 1 | More Info |
| 39 | KM1E33F-39 | SCREW ST4.8*12 | 1 | More Info |
| 40 | KM1E33F-40 | RECOIL SPRING | 1 | More Info |
| 41 | KM1E33F-41 | STARTER ROPE REEL | 1 | More Info |
| 42 | KM1E33F-42 | RECOIL STARTER BODY | 1 | More Info |
| 43 | KM1E33F-43 | OIL SEAL 12*30*7 | 1 | More Info |
| 44 | KM1E33F-44 | ROPE | 1 | More Info |
| 45 | KM1E33F-45 | STARTER HANDLE | 1 | More Info |
| 46 | KM1E33F-46 | CIRCLIP | 1 | More Info |
| 47 | KM1E33F-47 | SCREW M5*15 | 1 | More Info |
| 48 | KM1E33F-48 | CIRCLIP | 2 | More Info |
| 49 | KM1E33F-49 | CYLINDER COVER | 1 | More Info |
| 50 | KM1E33F-50 | WASHER | 1 | More Info |
| 51 | KM1E33F-51 | PLUG CAP | 1 | More Info |
| 52 | KM1E33F-52 | CLICK SPRING | 1 | More Info |
| 53 | KM1E33F-53 | PLUG COVER | 1 | More Info |
| 54 | KM1E33F-54 | SPARK PLUG | 1 | More Info |
| 55 | KM1E33F-55 | SCREW M5*20 | 4 | More Info |
| 56 | KM1E33F-56 | RATCHET | 1 | More Info |
| 57 | KM1E33F-57 | TORSIONAL SPRING | 1 | More Info |
| 58 | KM1E33F-58 | MUFFLER GASKET | 1 | More Info |
| 59 | KM1E33F-59 | MUFFLER COMP. | 1 | More Info |
| 60 | KM1E33F-60 | BOLT M5*45 | 2 | More Info |
| 61 | KM1E33F-61 | IGNITION COIL COMP. | 1 | More Info |
| 63 | KM1E33F-63 | CYLINDER | 1 | More Info |
| 64 | KM1E33F-64 | CYLINDER GASKET | 1 | More Info |
| 65 | KM1E33F-65 | PISTON RING | 2 | More Info |
| 66 | KM1E33F-66 | PISTON | 1 | More Info |
| 67 | KM1E33F-67 | STOP RING | 2 | More Info |
| 68 | KM1E33F-68 | PISTON PIN | 1 | More Info |
| 69 | KM1E33F-69 | NEEDLE BEARING | 1 | More Info |
| 70 | KM1E33F-70 | PISTON PIN CIRCLET | 2 | More Info |
| 71 | KM1E33F-71 | FUEL TANK CAP | 1 | More Info |
| 72 | KM1E33F-72 | O RING | 1 | More Info |
| 73 | KM1E33F-73 | AIR CHECK VALVE | 1 | More Info |
| 74 | KM1E33F-74 | INSIDE COVER | 1 | More Info |
| 75 | KM1E33F-75 | INLET FUEL PIPE | 1 | More Info |
| 76 | KM1E33F-76 | OUTLET FUEL PIPE | 1 | More Info |
| 77 | KM1E33F-77 | PRIMARY CORD GROMMET | 1 | More Info |
| 78 | KM1E33F-78 | FUEL FILTER | 1 | More Info |
| 79 | KM1E33F-79 | FUEL TANK | 1 | More Info |
| 80 | KM1E33F-80 | FUEL FILTER COMP. | 1 | More Info |
| 81 | KM1E33F-81 | SCREW M5*14 | 3 | More Info |
| 82 | KM1E33F-82 | STARTER PULLEY ASSY. | 1 | More Info |
| 83 | KM1E33F-83 | STARTER COMP. | 1 | More Info |
| 85 | KM1E33F-85 | LID | 1 | More Info |
| 86 | KM1E33F-86 | CHAIN | 1 | More Info |
| 87 | KM1E33F-87 | FUEL TANK LID COMP. | 1 | More Info |
